Sensitivity:
|
87.5dB (1W/1m)
|
|
Impedance:
|
Dual 4Ω
|
|
Peak Power (Watts):
|
1500
|
|
Recommended Amp Power (RMS):
|
375 - 750
|
|
Frequency Response:
|
39Hz - 150Hz
|
|
Voice Coil:
|
3.5" (8.89 cm)
|
|
Magnet Weight:
|
12.19 lbs (195 oz.)
|
|
Mounting Depth:
|
9.31" (23.65 cm)
|
|
Cut Out Diameter:
|
9.18" (23.34 cm)
|
|
Volume Displacement (Sd x Xmax):
|
55.73 cu in
|
|
Sealed Enclosure Net Volume:
|
1.25 cu ft
|
|
Tuning Frequency:
|
37Hz
|
|
RMS Power (Watts):
|
750
|
|
Vented Enclosure Net Volume:
|
1.25 cu ft
|
|
Speaker Displacement:
|
.14 cu ft
|
|
Sensitivity:
|
91dB (1W/1m)
|
|
Impedance:
|
Dual 4Ω
|
|
Peak Power (Watts):
|
2000
|
|
Recommended Amp Power (RMS):
|
500 - 1000
|
|
Volume Displacement (Sd x Xmax):
|
83.89 cu in
|
|
Magnet Weight:
|
16.25 lbs (260 oz.)
|
|
Frequency Response:
|
31Hz - 150Hz
|
|
RMS Power (Watts):
|
1,000
|
|
Voice Coil:
|
4.0" (10.16 cm)
|
|
Mounting Depth:
|
9.75" (24.77 cm)
|
|
Cut Out Diameter:
|
11" (27.94 cm)
|
|
Sealed Enclosure Net Volume:
|
1.5 cu ft
|
|
Vented Enclosure Net Volume:
|
1.75 cu ft
|
|
Speaker Displacement:
|
.19 cu ft
|
|
Tuning Frequency:
|
35Hz
|
|
Sealed Enclosure Net Volume:
|
2.0 cu ft
|
|
Tuning Frequency:
|
34Hz
|
|
Vented Enclosure Net Volume:
|
2.50 cu ft
|
|
Speaker Displacement:
|
.24 cu ft
|
|
Volume Displacement (Sd x Xmax):
|
135.77 cu in
|
|
Cut Out Diameter:
|
13.875" (35.24 cm)
|
|
Mounting Depth:
|
10.75" (27.31 cm)
|
|
Magnet Weight:
|
16.25 lbs (260 oz.)
|
|
RMS Power (Watts):
|
1000
|
|
Peak Power (Watts):
|
2000
|
|
Recommended Amp Power (RMS):
|
500 - 1000
|
|
Voice Coil:
|
4.0" (10.16 cm)
|
|
Frequency Response:
|
24Hz - 150Hz
|
|
Impedance:
|
Dual 4Ω
|
|
|
|
|
|
Sensitivity:
|
87.5dB (1W/1m)
|
|
Impedance:
|
Dual 4Ω
|
|
Peak Power (Watts):
|
1500
|
|
Recommended Amp Power (RMS):
|
375 - 750
|
|
Frequency Response:
|
39Hz - 150Hz
|
|
Voice Coil:
|
3.5" (8.89 cm)
|
|
Magnet Weight:
|
12.19 lbs (195 oz.)
|
|
Mounting Depth:
|
9.31" (23.65 cm)
|
|
Cut Out Diameter:
|
9.18" (23.34 cm)
|
|
Volume Displacement (Sd x Xmax):
|
55.73 cu in
|
|
Sealed Enclosure Net Volume:
|
1.25 cu ft
|
|
Tuning Frequency:
|
37Hz
|
|
RMS Power (Watts):
|
750
|
|
Vented Enclosure Net Volume:
|
1.25 cu ft
|
|
Speaker Displacement:
|
.14 cu ft
|
|
Sensitivity:
|
91dB (1W/1m)
|
|
Impedance:
|
Dual 4Ω
|
|
Peak Power (Watts):
|
2000
|
|
Recommended Amp Power (RMS):
|
500 - 1000
|
|
Volume Displacement (Sd x Xmax):
|
83.89 cu in
|
|
Magnet Weight:
|
16.25 lbs (260 oz.)
|
|
Frequency Response:
|
31Hz - 150Hz
|
|
RMS Power (Watts):
|
1,000
|
|
Voice Coil:
|
4.0" (10.16 cm)
|
|
Mounting Depth:
|
9.75" (24.77 cm)
|
|
Cut Out Diameter:
|
11" (27.94 cm)
|
|
Sealed Enclosure Net Volume:
|
1.5 cu ft
|
|
Vented Enclosure Net Volume:
|
1.75 cu ft
|
|
Speaker Displacement:
|
.19 cu ft
|
|
Tuning Frequency:
|
35Hz
|
|
Sealed Enclosure Net Volume:
|
2.0 cu ft
|
|
Tuning Frequency:
|
34Hz
|
|
Vented Enclosure Net Volume:
|
2.50 cu ft
|
|
Speaker Displacement:
|
.24 cu ft
|
|
Volume Displacement (Sd x Xmax):
|
135.77 cu in
|
|
Cut Out Diameter:
|
13.875" (35.24 cm)
|
|
Mounting Depth:
|
10.75" (27.31 cm)
|
|
Magnet Weight:
|
16.25 lbs (260 oz.)
|
|
RMS Power (Watts):
|
1000
|
|
Peak Power (Watts):
|
2000
|
|
Recommended Amp Power (RMS):
|
500 - 1000
|
|
Voice Coil:
|
4.0" (10.16 cm)
|
|
Frequency Response:
|
24Hz - 150Hz
|
|
Impedance:
|
Dual 4Ω
|
|
|
|
|
|
Sensitivity:
|
87.5dB (1W/1m)
|
|
Impedance:
|
Dual 4Ω
|
|
Peak Power (Watts):
|
1500
|
|
Recommended Amp Power (RMS):
|
375 - 750
|
|
Frequency Response:
|
39Hz - 150Hz
|
|
Voice Coil:
|
3.5" (8.89 cm)
|
|
Magnet Weight:
|
12.19 lbs (195 oz.)
|
|
Mounting Depth:
|
9.31" (23.65 cm)
|
|
Cut Out Diameter:
|
9.18" (23.34 cm)
|
|
Volume Displacement (Sd x Xmax):
|
55.73 cu in
|
|
Sealed Enclosure Net Volume:
|
1.25 cu ft
|
|
Tuning Frequency:
|
37Hz
|
|
RMS Power (Watts):
|
750
|
|
Vented Enclosure Net Volume:
|
1.25 cu ft
|
|
Speaker Displacement:
|
.14 cu ft
|
|
Sensitivity:
|
91dB (1W/1m)
|
|
Impedance:
|
Dual 4Ω
|
|
Peak Power (Watts):
|
2000
|
|
Recommended Amp Power (RMS):
|
500 - 1000
|
|
Volume Displacement (Sd x Xmax):
|
83.89 cu in
|
|
Magnet Weight:
|
16.25 lbs (260 oz.)
|
|
Frequency Response:
|
31Hz - 150Hz
|
|
RMS Power (Watts):
|
1,000
|
|
Voice Coil:
|
4.0" (10.16 cm)
|
|
Mounting Depth:
|
9.75" (24.77 cm)
|
|
Cut Out Diameter:
|
11" (27.94 cm)
|
|
Sealed Enclosure Net Volume:
|
1.5 cu ft
|
|
Vented Enclosure Net Volume:
|
1.75 cu ft
|
|
Speaker Displacement:
|
.19 cu ft
|
|
Tuning Frequency:
|
35Hz
|
|
Sealed Enclosure Net Volume:
|
2.0 cu ft
|
|
Tuning Frequency:
|
34Hz
|
|
Vented Enclosure Net Volume:
|
2.50 cu ft
|
|
Speaker Displacement:
|
.24 cu ft
|
|
Volume Displacement (Sd x Xmax):
|
135.77 cu in
|
|
Cut Out Diameter:
|
13.875" (35.24 cm)
|
|
Mounting Depth:
|
10.75" (27.31 cm)
|
|
Magnet Weight:
|
16.25 lbs (260 oz.)
|
|
RMS Power (Watts):
|
1000
|
|
Peak Power (Watts):
|
2000
|
|
Recommended Amp Power (RMS):
|
500 - 1000
|
|
Voice Coil:
|
4.0" (10.16 cm)
|
|
Frequency Response:
|
24Hz - 150Hz
|
|
Impedance:
|
Dual 4Ω
|
