JackHammer JH4512-04 12" Single 4 Ohm Subwoofer
MTX Audio JH45 Series
$119.95
FREE!**
1 Year
New
Please wait...
|
|
|
Finally a JackHammer that everyone can afford! Developed on the success of the ultimate subwoofer, The True 22-inch JackHammer SuperWoofer, comes JackHammer Series Subwoofers. When you put the name JackHammer on any subwoofer, you've got a reputation to protect. This series from MTX is designed to deliver the same hard hitting bass that MTX and the 22-inch JackHammer are known for! Designed and engineered in the U.S.A, JackHammer subwoofers are made of high quality materials and are packed with features that put other subwoofers to shame.
Features:
-
Precision Stamped Basket for greater structural integrity
-
FEA optimized roll geometry to maximize excursion without sacrificing cone surface area
-
Stitched Cone for added durability and style
-
ALDS Asymmetrical Linear Drive System with a flat progressive spider and extended pole piece for smooth, linear, piston like drive
-
Industry leading thermal power handling using 428 degree F High Temperature Voice Coil Wire
-
Industry Standard Cut Out Pattern for ease of installation
Specifications:
|
Part Number:
|
JH4512-04
|
|
Description:
|
12" Subwoofer
|
|
Impedance:
|
4 Ohm
|
|
Frequency Response (±3dB):
|
34-150Hz
|
|
RMS Power (Watts):
|
250 Watts
|
|
Recommended Amp Power (RMS):
|
125-250 Watts
|
|
Peak Power:
|
500 Watts
|
|
Sensitivity:
|
86.8dB
|
|
Voice Coil:
|
1.5" (3.81 cm)
|
|
Magnet Weight:
|
3.19 lbs (51 oz)
|
|
Mounting Depth:
|
5 1/2" (13.97 cm)
|
|
Cut Out Diameter:
|
11 1/16" (28.10 cm)
|
|
Impedance:
|
4Ω
|
|
Frequency Response:
|
35Hz - 150Hz
|
|
Sealed Enclosure Net Volume:
|
1.25 cubic feet
|
|
Vented Enclosure Net Volume:
|
2.0 cubic feet
|
|
RMS Power (Watts):
|
250
|
|
Recommended Amp Power (RMS):
|
125 - 250
|
|
Peak Power (Watts):
|
500
|
|
Sensitivity:
|
86.2dB (1W/1M)
|
|
Voice Coil:
|
1.50" (3.81 cm)
|
|
Magnet Weight:
|
48 oz.
|
|
Mounting Depth:
|
5.41" (13.74 cm)
|
|
Cut Out Diameter:
|
11.06" (28.10 cm)
|
|
Sealed Enclosure Net Volume:
|
1.25 ft³
|
|
Vented Enclosure Net Volume:
|
2.00 ft³
|
|
Volume Displacement (in³):
|
31.27
|
Downloads:
Items Shipped:
|
1
|
JackHammer JH4512-04 Subwoofer
|
|
1
|
Owners Manual
|
