MTX Audio TX68 Thunder Axe Separates 5" x 7" 2 Way Speaker System
$229.95*
FREE!**
1 Year
New
Please wait...
|
|
|
MTX’s Thunder Axe Separates are available in three models, TX6, TX5 and TX68
and offer a 6-1/2", 5-1/4" or 6” x 8" woofer (respectively) featuring a
polypropylene cone. Each offers a 2-way, 12dB/octave high-quality crossover
network that is designed and optimized for off-axis or on-axis listening. Models
also include a tunable tweeter network allowing for optimum imaging regardless
of placement or positioning. And if you’re looking for a tweeter-only model, the
TX1 is perfect for any application. These separates offer unmatched features and
sonic realism in their class.
Features:
-
Extended low frequency reproduction for bigger, fuller sound.
-
25mm soft dome tweeter can be mounted anywhere to improve imaging and exceed expectations, with the ability to clearly recreate the crispest highs.
-
The specially designed crossover uses mylar capacitors for superior signal integrity.
-
Concave cone design for improved off-axis response.
-
2-Way crossover and adjustable tweeter level.
-
Tweeter can be mounted in flush or surface mount adaptor and swivels within adaptor for superior imaging.
Specifications:
|
Part Number:
|
TX68
|
|
Cone Material:
|
Polypropylene
|
|
Tweeter:
|
25mm Soft Dome
|
|
Impedance:
|
4Ω
|
|
Frequency Response:
|
46Hz - 20kHz
|
|
RMS Power (Watts):
|
90
|
|
Peak Music Power (Watts):
|
180
|
|
Sensitivity:
|
92dB (2.83V/1m)
|
|
Voice Coil:
|
1.0" (2.54 cm)
|
|
Woofer Mounting Depth:
|
2.48" (6.3 cm)
|
|
Woofer Cut Out Diameter:
|
5" x 7.185" (12.7cm x 18.25cm)
|
|
Tweeter Mounting Depth:
|
1.0" (2.54 cm)
|
|
Tweeter Cut-out Diameter:
|
1.88" (4.76 cm)
|
|
Tweeter Mounting Options:
|
Flush or Surface (Angles in both)
|
|
Crossover:
|
2-Way, 18dB/6dB
|
|
Adjustable Tweeter Level:
|
0, -3
|
Items Shipped:
|
1
|
Pair of MTX Audio Thunder Axe TX68 Separates
|
|
1
|
Owners Manual
|
